Technical specifications
- Peak power
- 550 Wp
- Short-circuit current (Isc)
- 15.45 A
- Open-circuit voltage (Voc)
- 45.08 V
- Temp. coefficient of Voc
- -0.2 %/°C
- Series
- Hi-MO X10
Specification provenance: Unverified imported catalogue data — per-field datasheet citations are being added as documents are processed.
Dimensions & weight
- Width × Height × Depth
- 1990 × 1134 × 30 mm
- Weight
- 25.3 kg
Source: read from the manufacturer's datasheet.
Downloads
Frequently asked
- What are the dimensions of the LONGi Hi-MO X10 LR7-60HVH-550M (550W)?
- The LONGi Hi-MO X10 LR7-60HVH-550M (550W) measures 1990 mm wide × 1134 mm high × 30 mm deep. This figure is read from the manufacturer's datasheet.
- How much does the LONGi Hi-MO X10 LR7-60HVH-550M (550W) weigh?
- The LONGi Hi-MO X10 LR7-60HVH-550M (550W) weighs 25.3 kg (read from the manufacturer's datasheet).
- Where is the LONGi Hi-MO X10 LR7-60HVH-550M (550W) made?
- Our catalogue records the country of origin for the LONGi Hi-MO X10 LR7-60HVH-550M (550W) as CN (ISO 3166-1 alpha-2).
- Where can I download the LONGi Hi-MO X10 LR7-60HVH-550M (550W) datasheet?
- The LONGi Hi-MO X10 LR7-60HVH-550M (550W) datasheet is published by the manufacturer and linked from the Downloads section of this page. We link to the manufacturer's own copy so you always get the current revision.
